Dahua HDCVI 5.0MP Bullet 3.6mm B1A51 In order to use the 5MP 16:9 HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000001.0.R.200908 or later version. Max. 25 fps@5MP (16:9 video output) CVI/CVBS/AHD/TVI switchable 3.6 mm fixed lens (2.8 mm optional) Max. IR length 20 m, Smart IR IP67, DC12V Camera Image Sensor : 1/2.7" CMOS Effective Pixels : 2880 (H) × 1620 (V) Scanning System : Progressive Electronic Shutter Speed : PAL: 1/25~1/100000s / NTSC: 1/30~1/100000s Minimum Illumination : 0.02Lux/F1.85, 30IRE, 0Lux IR on S/N Ratio : More than 65dB IR Distance : Up to 20m  IR On/Off Control : Auto / Manual Lens Lens Type : Fixed lens / Fixed iris Mount Type : M12 Focal Length : 3.6mm Max Aperture : F2.0 Angle of View : 104° × 88° × 46°(diagonal × horizontal × vertical) Focus Control : N/A Close Focus Distance : 1.2m  Video Resolution : 5M (2880 × 1620); 4M (2560 × 1440); 1080P (1920 × 1080); 960H (960 × 576/960 × 480) Frame Rate : CVI:PAL:5M@25 fps; 4M@25 fps; 1080P@25 fps; 5M@25 fps / NTSC:5M@25 fps;4M@30 fps; 1080P@30 fps; 5M@25 fps / AHD:PAL:4M@25 fps; / NTSC:4M@30 fps; / TVI:PAL:4M@25 fps; / NTSC:4M@30 fps; / CVBS:960H; Video Output : 1-channel BNC high definition video output / CVBS video output (Can switch) Day/Night : Auto (ICR) / Manual OSD Menu : Multi-language BLC Mode : BLC / HLC / DWDR WDR : DWDR Gain Control : AGC Noise Reduction : 2D White Balance : Auto / Manual Smart IR : Auto / Manual Mirror : Off/On Privacy Masking : Off / On (8 area, rectangle) Certifications CE (EN55032, EN55024, EN50130-4,EN60950-1, EN 62368-1:2014+A11:2017) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) Interface Audio Interface : N/A Eelectrical Power Supply : 12V DC ±30% Power Consumption : Max. 3.7W (12V DC, IR on) Environmental Operating Conditions : -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH * Start up should be done at above -40°C (-40°F) Storage Conditions : -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH Ingress Protection & Vandal Resistance : IP67 Construction Casing : Plastic Dimensions : 69.8 mm × 69.8 mm × 149.3 mm Net Weight : 0.15 kg Gross Weight : 0.25 kg
