Condition: New, 2025 Technical information: ● BWL – 1400 meters ● NWL – 1080 meters ● HWL – 725 meters ● PWL – 480 meters Hydraulic system: ● Manufacturer: Parker (США) ● Primary Pump: 165 L/m, 31 MPa ● Secondary Pump: 64 L/m, 21 MPa ● Auxiliary Pump: 42 L/m, 14 MPa Drill Head: ● Rotation unit moving aside by h/cylinder ● Drill Head PQ with Funk 4 speed mechanical transmission ● Spindle diameter: 127 mm ● Axial holding capacity: 222,4 KN ● Rexroth hydraulic motor Drill Mast: ● Consists telescopic and dump mast ● Feed Stroke: 3,35 m ● Drilling Angle: 40-90° ● Feed Pull: 167.7 kN ● Feed Thrust: 88.4 kN ● Rod Pull: 6,0 m Rod holder: ● Max hole diameter w/o jaws – 210 мм. ● Axial holding capacity 200 KN Wireline hoist: ● Pull – 228 kg / 993 kg (Full Drum/ Bare Drum) ● Cable diameter 4,8 mm ● Drum Capacity– 1 890 m Wet Weight: ● 14000 kg Transport Position dimensions: ● Length – 7010 mm ● Width – 2501 mm ● Height – 3014 mm Standard equipment: ● Feed Stroke 3.5 m ● Main hoist BRADEN with force of 7 258 kg ● Main draw works cable 22,4 meters ● Cable wireline 1200 meters ● Mud Mixer Assembly ● Jaws for hydro chuck NWL, HWL, PWL ● Jaws for rod holder NWL, HWL, PWL
